Mastervolt pure sine wave inverters have proven their quality under extreme conditions for more than 25 years. Our inverter family consists of AC Master, Mass Sine and Mass Sine Ultra models, from 300W up to 40kW. The AC Master is ideal for small to medium applications, while the Mass Sine inverters and advanced Mass Sine Ultra are designed for larger systems and professional use.
AC Master Series: Safe AC power for recreational and semi-professional use
These affordable pure sine wave inverters convert 12V or 24V battery voltage to stable 230V 50/60Hz or 120V 50/60Hz mains voltage, and are ideal for recreational and semi-professional applications. The AC Master series inverters are easy to install and provide maximum power even in difficult conditions. The pure sine wave form guarantees energy of absolute quality, essential for the functioning of sensitive equipment. The use of high-frequency switching technology eliminates any hum and vibration noise.
These robust inverters ensure the comforts of home when you are away from the grid, with excellent value for money.
- Pure sine wave protects sensitive equipment.
- They deliver full power and high peaks even under difficult conditions.
- Automatic energy saving system for extended use.
- Compact and lightweight design, saving time in installation.
- Reliable and safe: protected against overtemperature, overload, short circuit, high and low battery voltage.
- Variable speed fan reduces noise at low powers.
- Optional remote control for switching off the inverter and connected equipment (not available for 300 and 500 W models).
- Practical sockets for all models. Models 2500/3500 also equipped with clamps.
In addition, the 2500/3500 Watt models offer:
- Possible parallel from 2 to 15 units for high power or three-phase systems.
- Automatic transfer system between AC sources.
Both recreational and semi-professional use, where there is a shortage or lack of electricity. Among the applications: lighting, household appliances, electric cookers and utensils. For (mobile) applications in the home, office, utility vehicles, or on vacation.
|Output voltage||200/220/230/240V – 50/60Hz (programmable)|
|Output waveform||pure sine wave|
|Nominal battery voltage||12V|
|Recommended battery capacity||≥130Ah|
|Continuous power at 25°C / 77°F, cos phi 1||1000W|
|Continuous power at 40°C / 104°F, cos phi 1||1000W|
|Peak power (1 min.)||< 1150W|
|Peak power (1 sec.)||< 1750W|
|AC connection||EU socket (Schuko), with UK plug (art.n. 28211000) or with NZ/AU plug (art.n. 28411000)|
|Efficiency||ninety two %|
|Displays/readings||LED indicators: battery voltage, AC load level and status|
|Alarms||clean alarm contact|
|Dimensions, hxwxd||200 x 372 x 83mm
7.9 x 14.6 x 3.3 inches
|Certifications||CE, E-mark, RCM|
|Technology||high frequency, isolated input and output|
|Shutdown due to low battery voltage||10.5V|
|Recovery from low battery voltage||12.5V|
|Shutdown due to high battery voltage||16.5V|
|Recovery from high voltage batteries||14.5V|
|Current consumption (at nominal load)||100A|
|Self-consumption (ON mode)||< 1.5A|
|Self-consumption (energy saving mode)||< 0.1A|
|DC fuse minimum size (slow blow)||125A|
|Minimum section of the cable||35mm²|
|Harmonic Distortion (typical)||< 5 %|
|Cos phi||all cos phi allowed|
|Room temperature||-20 °C to 60 °C, power reduction > 40 °C
-4°F to 140°F
|Cooling down||controlled temperature and load fan|
|Degree of protection||IP21, horizontal wall mounting|
|Protectors||over temperature, overload, short circuit, high/low battery voltage, reverse polarity (fuse)|
